THEBE TP-70 JUNIOR Peripheral Water Pump

$89.00

  • Cast iron casing and intermediate with anti-clogging protection.
  • Brass impeller
  • Stainless steel shaft tip (prevents premature corrosion).
  • Housing sealing O-ring in Buna N. Mechanical seal: Faces in graphite and ceramic.
  • Spring in stainless steel 304 elastomer (rubber) in Buna N.
  • Use for clean water, agriculture/irrigation, residential and civil construction.
Coming soon
Availability: Out of stock SKU: 2134528000018 Category:

Description

Product Specifications
Product Type Household Appliance
Product Name THEBE TP-70 JUNIOR Peripheral Water Pump
Marca THEBE
Model Number TP-70 JUNIOR
Power 3/4 HP (0.37 kW)
Maximum height 40 m
Maximum flow rate 3,1 m³/h
Minimum Flow Rate 0,1 m³/h
Maximum Pressure 40,0 mca
Minimum Pressure 2.0 mca
Maximum suction depth 5 m
Inlet Diameter 1″ NPT
Outlet Diameter 1″ NPT
Speed 3500 rpm
Duty Cycle 24 Hours // No rest interval required, within electrical and operating parameters
Voltage / Frequency Single voltage on II Pole, 60Hz, Voltage = 127V // Max. current = 7.3A
Consumption 0.55 kW
Total weight of the set Gross 4.46 Kg // Net = 4.42 Kg
Size 14,9 x 12,5 x 25 (cm)
